20C-UAE OEM Thermal Power/Energy Laser Sensor

Updated:2023-06-01

Brand：Ophir
Model：20C-UAE
Description: The 20C-UAE is a compact OEM thermal power/energy laser sensor with dimensions only 38x38x14mm. It has a 12mm aperture and measures from 10mW to 4W stand alone and 20W when heat sinked. It can measure
Data download

Feedback
WeChat

QQ

Online Service

Product Details

20C-UAE OEM Thermal Power/Energy Laser Sensor Description：

The 20C-UAE is a compact OEM thermal power/energy laser sensor with dimensions only 38x38x14mm. It has a 12mm aperture and measures from 10mW to 4W stand alone and 20W when heat sinked. It can measure energy from 6mJ to 10J. Its broadband coating covers the spectral range from 0.19 to 20µm. It has Ethernet output.

20C-UAE OEM Thermal Power/Energy Laser Sensor Drawing：

20C-UAE Drawing

20C-UAE OEM Thermal Power/Energy Laser Sensor Specifications：

Aperture	Ø12mm
Spectral Range	0.19-20µm
Power Range	10mW-20W
Energy Range	6mJ-10J
Dimensions	38 L x 38 W x 14 D (mm)
Max Average Power Density	23kW/cm² at 20W
Response Time	0.8 s
Max Energy Density(for <100ns)	0.3J/cm²
Max Energy Density(for 2ms)	10 J/cm²
Max Average Power	20W heat sinked
Communication	Ethernet
