Jewell Model C904 Clinometer Pak 420

Updated:2026-01-24

Brand: Jewell
Model: Model C904
Description: The Clinometer Pak 420 is the packaged version of our Tulip 4-20 mA clinometer. Its rugged aluminum enclosure provides mechanical and environmental protection for indoor or outdoor use. This uniaxial
Data download

Feedback
WeChat

QQ

Online Service

Product Details

Jewell Model C904 Clinometer Pak 420 Description：

Datasheet Outline Drawing

The Clinometer Pak 420 is the packaged version of our Tulip 4-20 mA clinometer. Its rugged aluminum enclosure provides mechanical and environmental protection for indoor or outdoor use. This uniaxial instrument is current loop-powered, so measurements can be made over long cables using an economical 2-wire pair. It also measures temperature using a built-in thermistor. Use it to monitor the angular position of conveyers, booms, ramps, and machinery; perform antenna tilt error corrections; and track the pitch and roll of ships, buoys, ROVs, and towfish.

Specifications

	High-Gain	Standard	Wide-Angle
Angular Range (°)	±10	±25	±50
Resolution (°)¹	0.005	0.01	0.02
Repeatability (°)	0.02	0.02	0.02
Scale Factor (°/mA)²	1.25	3.125	6.25
Non-linearity (%)³	1	2.5	7
Output Voltage (V)	4-20mA, 2-wire current loop
Channels	Tilt, Thermistor
Kz Coefficient (°/C, typical)	10-20 arcsec
Ks Coefficient (%/C, typical)	0.03
Time Constant (seconds)	0.15
Natural Frequency (Hz)	10
Power	(0.02 Ampere x R + 10 VDC) < Vs < 29 VDC
Environmental	-40 to +85°C operation and storage. IP65
Materials	Die-cast aluminum, painted
Cable	3m (10ft), 5-conductor + one overall shield, PVC jacket, tinned ends
