Trek 603 Series

Trek 603 Series Description：

Datasheet

The Trek® 603 is a high-voltage DC power amplifier/piezo driver designed to provide precise control of output voltages in bipolar or unipolar ranges that are customer specified within a range of available settings. The instrument achieves the accurate output responses and high slew rates demanded by reactive loads by utilizing a four-quadrant active output stage that sinks or sources current into reactive or resistive loads. The Trek 603 is configured as a non-inverting amplifier and is available in single or dual channel packaging that are operable on a bench top or in a 19 in rack.

Select from Available Ranges and Options. The Trek 603 high-voltage amplifier/piezo driver offers precise control of output voltages in customer-specified bipolar or unipolar ranges.

Meet the Demands of Reactive Loads. The Trek 603 achieves accurate output responses and high slew rates by utilizing a four-quadrant active output stage that sinks or sources current into reactive or resistive loads. It’s configured as a non-inverting amplifier and is available in single or dual-channel packaging.

Features

Up to two independent amplifier channels in one enclosure

CE compliant for assured reliability

Reprogrammable factory-set output configurations

Dynamic Adjustment to optimize the AC response for various load parameters

Load range switch

Benefits

Use on a benchtop or in a 19-in rack

Drive capacitive loads via a four-quadrant output

Enable high accuracy thanks to a closed-loop system

Safeguard equipment with short-circuit protection

Take advantage of low-output noise and ultra-accurate outputs

Specifications
